Deadband: 0.1 fps ± 15 %
Compliance: CE
Wire Gauge: 22 AWG
Switch Note: 400 mA, derate 5 mA/°C above 23°C
Switch Type: NPN NO, NPN NC
Deadband Note: 0.1 ft/s (0.03 m/s) +15% of setpoint
Pressure Type: Gauge
Repeatability: 0.07 fps + 3%
Response Time: 8 s
Switch Rating: 400 mA
Velocity, Max: 10 ft/s
Velocity, Min: 0.5 ft/s
Pipe Size, Max: 10 in
Pipe Size, Min: 2 in
Supply Voltage: 9 to 24 Vdc
Pressure Limits: Up to 300 psi
Sensor Material: 316 Stainless steel
Enclosure Ratings: IP65, NEMA Type 4X
Power Consumption: Average: 93 mA, Peak: 300 mA
Supply Power Type: DC
Enclosure Material: 316 Stainless Steel, Stainless Steel, Polycarbonate, Neoprene
Repeatability Note: 0.07 ft/s (0.02 m/s) +3% of setpoint
Media Compatibility: Water-based fluids
Electrical Connection: 1/2 NPT female Conduit with Cable
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 140 °F
Process Temperature, Min: 5 °F
Storage Temperature, Max: 185 °F
Storage Temperature, Min: -40 °F
Input Power and Protection: 0.5A Fuse (resettable) Reverse Polarity Protected
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 5 °F
Switched Output Protection: 0.5A Fuse (resettable) Reverse Polarity Protected
