Weight: 13.23 lb
Accuracy: ± 0.5 %
Materials: ABS
Turbidity: <3% by Volume of Particulate Content
Compliance: CE
Weight Note: Unit without Accessories: 2.3, Unit with Accessories in Carring Case: 13.23
Display Note: 240 x 64 pixel graphic display, high contrast black on white with backlight; Languages: English, French, German, Swedish, Italian, Spanish, Portuguese, Russian, Norwegian, and Dutch; 5.2˝ W x 1.5˝ H
Display Type: LCD
Accuracy Note: ± 0.5 to 2% of flow reading for flow rate > 0.66 ft/s (0.2 m/s) and pipe ID > 2.95 in (75 mm); ± 3% of flow reading for flow rate > 0.66 ft/s (0.2 m/s) and pipe ID in range 0.512 to 2.95˝ (13 to 75 mm); ± 6% of flow reading for flow rate < 0.66 ft/s (0.2 m/s)
Output Detail: Analog: 1 opto-isolated output: 4-20 mA, 0-16 mA or 0-20 mA (selectable); Error current: 0-26 mA (selectable); Load resistance: 620 Ω max; Pulse: 1 opto-isolated MOSFET relay, 150 mA max, 500 pps max, 200 Hz max
Output Signal: Current, DC Pulse
Repeatability: ± 0.5%
Response Time: <500 ms
Data Interface: USB, RS232
Pipe Size, Max: 78 in
Pipe Size, Min: 0.5 in
Supply Voltage: 9 to 24 Vdc
Load Resistance: 620 Ω max
Enclosure Ratings: IP51, IP54
Power Consumption: 10.5 W
Supply Power Note: 9-24 VDC, (1) 5-Cell NiMH battery, internal, factory replaceable (continuous operation time: 20 hours with back-light and output off) (recharging time: 6.5 hours, power adaptor used)
Supply Power Type: DC/Battery
Power Adaptor Size: 110/240 Vac Adaptor. UK,US, European Adaptors Included
Repeatability Note: ± 0.5% of measured value or ± 0.066 ft/s (0.02 m/s)
Media Compatibility: Liquids
Tube Wall Thickness: 3 in
Battery Size and Type: NiMh
Electrical Connection: Lemo 7-pin with cable
Linear Flow Rate, Max: 65.62 ft/s
Linear Flow Rate, Min: 0.33 ft/s
Permissible Air Content: <3% by Volume
Operating Temperature, Max: 275 °F
Operating Temperature, Min: -4 °F
