Weight: 16 oz
Accuracy: ± 0.25 %
Impedance: Current: 10 Ω/Voltage: 100 kΩ
Isolation: 24 Vdc @ 50 mA, Regulated
Compliance: cULus
Input Type: Current, Voltage
Switch Note: Control relays: SPDT, rated 10 A @ 240 VAC res., 1/4 hp @ 120 VAC, 1/3 hp @ 240 VAC; Alarm relays: SPST, 3 A @ 240 VAC res., 1/10 hp @ 120 VAC.
Switch Type: SPDT, SPST
Control Mode: On/Off, Reverse/Direct Acting
Display Note: Two 4-digit, 7 segment 0.56˝ high LED’s
Display Type: LED
Seal Failure: Moisture Sensor: Power: 2.5 Vdc; Search Current: 3 µA; Resolution: 10k to 500kΩ in 10kΩ steps
Accuracy Note: ± 0.25% of span, ± 1 least significant digit
Memory Backup: Non-Volatile
Switch Rating: Control Relays: SPDT, rated 10 A @ 240 Vac, 1/4 hp @ 120 Vac, 1/3 hp @ 240 Vac; Alarm Relays: SPST, 3 A @ 240 Vac, 1/10 hp @ 120 Vac
Data Interface: RS235, Modbus
Supply Voltage: 100 to 240 Vac
Enclosure Ratings: IP66, UL Type 4X
Power Consumption: 7.5 VA
Relative Humidity: 0 to 90% Non-Condensing
Supply Power Note: 100-240 Vac nominal, +10%-15%, 50 to 400 Hz, single phase; 132 to 240 Vdc nominal, +10%-15%.
Supply Power Type: AC
Display Resolution: 1 Count
Relative Humidity Note: 14 to 131°F/0 to 90% up to 104°F (40°C) Non-Condensing, 10 to 50% at 131°F (55°C) Non-Condensing
Current Measurement Range: 4 to 20 mA
Voltage Measurement Range: 0 to 10 Vdc
Operating Temperature, Max: 131 °F
Operating Temperature, Min: 14 °F
