Weight: 23 oz
Accuracy: ± 5 %
Division: 0
Compliance: CE, cULus
Dial Depth: 4.125 in
Wire Gauge: 22 to 12 AWG
Switch Note: 5 A @ 120/240 VAC resistive; 5 A @ 30 VDC
Switch Type: (2) SPDT
Accuracy Note: ± 5% of FS @ 70°F (21.1°C)
Pressure Type: Differential
Pressure, Max: 20 inH₂O
Pressure, Min: 0 inH₂O
Switch Rating: 5 A @ 120/240 Vac, 5 A @ 30 Vdc
Proof Pressure: Up to 30 psi
Supply Voltage: 24 Vac/Vdc
Materials, Wetted: Consult Factory
Supply Power Note: 24 VDC / 24 VAC 50/60 Hz 4 watts
Supply Power Type: AC/DC
Dial Outer Diameter: 3.0625 in
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Vertical
Set Point Adjustment: Push-button
Standard Accessories: (2) Mounting Screws, (1) .050" Hex Allen Wrench
Electrical Connection: Screw Terminal
Process Connection Note: Barbed for 3/16˝ ID tubing (STD); 1/8˝ male NPT (optional)
Process Connection Size: 3/16 in
Process Connection Type: Barbed Fitting
Operating Temperature, Max: 120 °F
Operating Temperature, Min: 20 °F
