Drift: <5%/Year in Air
Weight: 1 lb
Accuracy: ± 5 ppm or 5 %
Materials: Glass-Filled Polycarbonate
Set Point: Selectable 25, 60, or 150 PPM
Compliance: CE, UL
Resolution: 1 ppm
Sensor Life: 5 Years
Sensor Type: Electrochemical
Switch Type: SPDT NO/NC, Selectable
Display Type: N/A
Relay Output: Factory Set for Direct Acting
Coverage Area: 7500 sq ft
Output Detail: Jumper selectable 4-20 mA (loop powered) or 2-10 V (max. load 2 kΩ)
Output Signal: Current, Voltage
Response Time: <45 s to 90%
Switch Rating: NO: 5 A @ 30 Vdc, 250 Vac; NC: 3 A @ 30 Vdc, 250 Vac
Enclosure Type: IP64
Compliance Note: Sensor is UL recognized component for ANSI/UL-2034, UL-2075, E340403, CE
Gas Concentration: 0 to 300 ppm
Relative Humidity: 15 to 90% RH Constant, 0 to 99% RH Intermittent
Calibration Option: Factory Calibration Certificate
Temperature Effect: ± 2% Over Range
Additional Features 1: Factory Calibration Certificate
Storage Temperature, Max: 68 °F
Storage Temperature, Min: 32 °F
Operating Temperature, Max: 122 °F
Operating Temperature, Min: -4 °F
Zero Setting Adjustable Range: 15 Turn Potentiometers
Set Point Differential/Hysteresis: 3 % scale
