Weight: 4.16 lb
Accuracy: ± 6 %
Compliance: CE
Display Note: 4-digit alpha numeric red LED
Display Type: LED
Accuracy Note: Class 1.4.1: ± 3% of measured value +0.3% of full-scale value; Class 3.4.4: ± 6% of measured value + .6% of full-scale value.
Output Detail: pulse, 4 to 20 mA; Output 1: PNP open collector: VOUT(max)=30 VDC / ISINK(max)=250mA; Output 2: 4-20 mA (scaleable) or PNP open collector.
Output Signal: Current, DC Pulse
Pressure Type: Gauge
Response Time: <0.1 s
Supply Voltage: 19 to 30 Vdc
Loop Resistance: 500 Ω
Pressure Limits: Up to 232 psi
Number of Digits: 4
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: 304 Stainless Steel, Anodized Aluminum, Ceramic, Fluoroelastomer, PEEK, Polyester
Power Consumption: <100 mA
Relative Humidity: 90% RH
Supply Power Type: DC
Media Compatibility: Air, Argon, Clean Dry Air, Nitrogen
Mounting Orientation: Horizontal, Vertical
Electrical Connection: M12 4 pin Male
Process Connection Size: 1 in
Process Connection Type: NPT Male
Volumetric Flow Rate, Max: 132.4 SCFM
Volumetric Flow Rate, Min: 1 SCFM
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 32 °F
