Filter: 0.5 to 15 s (Selectable)
Weight: 13.9 oz
Accuracy: ± 3 %
Cable Length: 6 ft
Display Note: 4-1/2 digit 1/2˝ red LED
Display Type: LED
Probe Length: 12 in
Accuracy Note: 3% FS process gas: 32 to 122°F (0 to 50°C); 4% FS process gas: -40 to 32°F and 122 to 212°F (-40 to 0°C and 50 to 100°C)
Output Detail: 4 to 20 mA, isolated 24 V source, 3 or 4-wire connection
Response Time: 1.5 s to 95%
Probe Diameter: 0.3125 in
Supply Voltage: 10 to 16 Vac, 12 to 35 Vdc
Loop Resistance: 600 Ω max
Number of Wires: 4
Pressure Limits: Up to 100 psi
Number of Digits: 4.5
Air Velocity, Max: 15000 FPM
Air Velocity, Min: 250 FPM
Electrical Output: 4 to 20 mA
Power Consumption: 300 mA
Relative Humidity: Non-Condensing
Supply Power Note: 12 to 35 Vdc, 10 to16 Vac. 1.5 A rating required on supply due to initial power surge drawn by transmitter
Supply Power Type: AC/DC
Display Resolution: 1 FPM, 0.01 MPS (10 FPM @ 10,000 and 15,000 FPM ranges)
Response Time Note: Flow: 1.5 s to 95% of final value (output filter set to minimum)
Media Compatibility: Argon, Carbon dioxide, Clean Dry Air, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: None
Electrical Connection: Screw Terminal
Process Temperature, Max: 212 °F
Process Temperature, Min: -40 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 32 °F
