Weight: 51 g
Accuracy: ± 1 %
Compliance: CE
Display Type: N/A
Mounting Note: Vertical with Downward Pressure Ports
Output Detail: Field Selectable
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 3 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 2 psi
Supply Voltage: 3-Wire (5V): 10 to 35 Vdc, 4-Wire (5V): 12 TO 26 Vac, 2-Wire or 3-Wire (10V): 16 to 36 Vdc, 4-Wire (10V): 20 to 28 Vac
Loop Resistance: 5 kΩ min
Number of Wires: 2, 3, 4
Span Adjustment: Push Button
Thermal Effects: ± 0.04% FS/°F
Electrical Output: 0 to 5Vdc, 1 to 5Vdc, 0 to 10Vdc, 2 to 10 Vdc
Enclosure Ratings: IP20, NEMA Type 1
Materials, Wetted: Consult Factory
Power Consumption: max 24 mA
Supply Power Type: AC/DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Thermal Effects Note: ± 0.04% FS/°F, includes zero and span.
Electrical Connection: Screw Terminal
Process Connection Note: Barbed, dual size to fit 1/8˝ and 3/16˝ (3 mm and 5 mm) ID rubber or vinyl tubing
Process Connection Size: 1/8 in, 3/16 in
Process Connection Type: Stepped Barb Fitting
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -17.8 °C
Compensated Temperature, Max: 50 °C
Compensated Temperature, Min: -6.67 °C
Zero Setting Adjustable Range: Push button
