Weight: 1.8 lb
Accuracy: ± 3 %
Dial Dia: 4 in
Division: 0.5 mmH2O
Compliance: CE
Dial Depth: 3.125 in
Switch Note: Each set point has 1 form C relays (SPDT), Relay Contacts: (Resistive load) 1 form C rated 1.0A @ 30 VDC, 0.3A @ 110 VDC or 0.5A @ 125 VAC, Gold over clad silver - suitable for dry circuits
Switch Type: SPDT NO/NC, Selectable
Accuracy Note: ± 2% of FS (3000-0 ± 3% of FS). (3000-00 ± 4% of FS)
Pressure Type: Differential
Pressure, Max: 10 mmHg
Pressure, Min: 0 inH₂O
Switch Rating: 1 A @ 30 Vdc, 0.3 A @ 110 Vdc / 0.5 A @ 125 Vac
Proof Pressure: -20 inHg to 25 psi
Supply Voltage: 24 Vdc
Materials, Wetted: Consult Factory
Supply Power Note: 24 Vdc, regulated ± 10%
Supply Power Type: DC
Dial Outer Diameter: 5 in
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Vertical Diaphragm
Set Point Adjustment: Adjustable Knobs
Electrical Connection: Cable
Process Connection Note: 1/8˝ female NPT (duplicated side and back)
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 120 °F
Operating Temperature, Min: 20 °F
