Weight: 1.64 kg
Deadband: 0.1 to 0.2 inH2O
Compliance: CE
Switch Note: 15 A @ 120-480 VAC, 60 Hz. Resistive, 1/8 HP @ 125 VAC,1/4 HP @ 250 VAC, 60 Hz
Switch Type: SPDT NO/NC, Selectable
Pressure, Max: 1.5 inH₂O
Pressure, Min: 0.15 inH₂O
Repeatability: ± 1%
Switch Rating: 15 A @ 120-480 Vac, 1/8 HP @ 125 Vac, 1/4 HP @ 250 Vac
Proof Pressure: Up to 50 inH2O
Materials, Wetted: Consult Factory
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Vertical Diaphragm
Set Point Adjustment: Screw Adjustment
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 130 °F
Operating Temperature, Min: -30 °F
