Battery
• Type: Li-Ion, 14.8 V, 2.9 Ah
• Rechargeable
• User replaceable
Power Supply Adapter
• Input voltage: 90 – 264 V AC, 50/60 Hz
• Output voltage: 12-19 V DC
• Output current: 2 A DC
Output DC Source 1
• Current: 2 A, 1 A, 500 mA, 100 mA, 50 mA, 10 mA, 5 mA
Output DC Source 2
• Current: 10 A, 5 A, 2 A, 1 A, 500 mA
Winding Resistance Measurement
• Measurement range: 1 µΩ – 3 kΩ
• Range / resolution:
1 µΩ – 9.999 mΩ/ 1 µΩ
10.00 mΩ – 99.99 mΩ/ 0.01 mΩ
100.0 mΩ – 999.9 mΩ/ 0.1 mΩ
1.000 Ω – 9.999 Ω/ 0.001 Ω
10.00 Ω – 99.99 Ω/ 0.01 Ω
100.0 Ω – 999.9 Ω/ 0.1 Ω
1.000 kΩ – 3.000 kΩ/ 1 Ω
• Typical accuracy: ±(0.5% rdg + 0.5% F.S.)
Display: LCD 4.8” display, 240 x 128 pixels
Environmental Conditions
• Operating temperature: -20 ºC – +55 ºC / -4 ºF – +131 ºF
• Storage & transportation: -40 ºC – +70ºC / -40 ºF – +158 ºF
• Humidity: 0% – 95% relative humidity, noncondensing
Dimensions and Weight
• Dimensions (W x H x D): 170 x 310 x 58 mm / 6.69 x 12.21 x 2.28 in
• Weight: 1.4 kg / 3.1 lbs
