Work plate dimension (WxD): 184x184mm (7 inch)
Work plate material: Glass ceramic
Motor type: Brushless DC motor
Stirring positions: 1
Max. stirring quantity (H2O): 20L
Max. magnetic bar (length): 80mm
Speed range: 100~1500rpm; resolution: ±1rpm
Speed display: LCD
Temperature display: LCD
Heating temperature range: Room Temp.~550°C, increment: 1°C
Temperature control accuracy: ±1°C (<100°C); ±1%(>100°C)
Overheating protection: 580°C
Temperature display accuracy: ±0.1°C
External temperature sensor: PT1000 (accuracy: ±0.2)
"Hot" warning: 50°C
Data connector: RS232
Protection class: IP21
Motor rating input: 18W
Motor rating output: 10W
Power: 1050W
Heating output: 1000W
Voltage: 100~120/200~240V; 50/60Hz
Dimension (WxDxH): 215x360x112mm
Weight: 5.3kg
Permissible ambient temperature and humidity: 5~40°C, 80%RH
Please choose the EURO plug when ordering:
+ Euro plug, 200V~240V/50Hz/60Hz
Included accessories: PT1000A (18900016)
Optional accessories (refer to datasheet page 72-73)
