Work plate dimension: φ135mm (5inch)
Work plate material: Aluminum cover with ceramic coating
Motor type: Brushless DC motor
Heating temperature range: Room temp.~340°C, increment: 1°C
Temperature display accuracy: ±0.1°C
Speed range: 100~1500rpm
Resolution: ±1rpm
Max. stirring quantity [H2O]: 20L
Speed display: LCD
Temperature display: LCD
Max. magnetic bar [length]: 80mm
Temperature control accuracy: ±1°C (<100°C); ±1%(>100°C)
External temperature sensor: PT1000 (accuracy: ±0.2°C)
Over temperature protection: 420°C
"Hot" warning: 50°C
Data connector: RS232
Protection class: IP21
Voltage: 100~120/200~240V; 50/60Hz
Heating power: 600W
Power: 650W
Motor rating input: 18W
Motor rating output: 10W
Dimension (WxDxH): 280×160×100mm
Weight: 2.8kg
Permissible ambient temperature and humidity: 5~40°C; 80%RH
Please choose the EURO plug when ordering:
+ Euro plug, 200V~240V/50Hz/60Hz
Included accessories: PT1000A (18900016) & 1 protective cover 18100374 (18900019 for standalone package)
