Fall Time: 423.8 ns
Rise Time: 155.1 ns
Technology: Si
Unit Weight: 0.800 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 9.1 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 530 mW
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 80.4 ns
Typical Turn-Off Delay Time: 688.1 ns
Id - Continuous Drain Current: 2.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 36 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1 V
