Shutdown: No Shutdown
Topology: Dual
Input Type: Rail-to-Rail
Technology: CMOS
Output Type: Rail-to-Rail
Unit Weight: 534.825 mg
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 450 mV/us
THD plus Noise: - 70 dB
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.6 V
Ib - Input Bias Current: 1 pA
Operating Supply Current: 70 uA
Vcm - Common Mode Voltage: - 300 mV to 5.3 V
Ios - Input Offset Current: 1 pA
Output Current per Channel: 150 mA
Vos - Input Offset Voltage: 500 uV
GBP - Gain Bandwidth Product: 1 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 27 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 90 dB
PSRR - Power Supply Rejection Ratio: 80 dB
