Color: Green
Width: 32.49 mm
Gender: Receptacle (Female)
Height: 32.49 mm
Length: 42.18 mm
Material: Plastic
Dimensions: 32.49 mm x 32.49 mm x 42.18 mm
Insulation: Insulated
Unit Weight: 42.092 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: HD16-9-1939SX-P080, HD17-9-1939SX-P080
Number of Positions: 9 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
