Color: Gray
Width: 29.57 mm
Gender: Receptacle (Female)
Height: 29.57 mm
Length: 41.63 mm
Material: Plastic
Dimensions: 29.57 mm x 29.57 mm x 41.63 mm
Insulation: Insulated
Application: Wire to Wire
Unit Weight: 19.300 g
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Mounting Flange
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 14 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: HD16-3-96SX-XXXX
Flammability Rating: UL 94 V-1
Number of Positions: 3 Position
Attachment Hole Diameter: 1.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
