Maxinmum working pressure: 3 bar(g) (43.5 psig)
Capacity(FAD)*:
50Hz: 31.5-63 m³/min ( equivalent to 1113-2225 cfm)
60Hz: 34.65-69.3 m³/min ( equivalent to 1224-2447 cfm)
Installed motor power: 250 kW; 350 hp
driving mode & Cooling method: Direct Driven & W-Water Cooling
Noise level **db(A) : 82
Dimensions(mm) LxWxH: 4300x2400x2350
Weight (kg): 6600
Air outlet pipe diamete: DN100
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
Specifications are subject to change without notice.
