Width: 115 mm (4.528 in)
Height: 50 mm (1.969 in)
Length: 215 mm (8.465 in)
Industry: Industrial
Approvals: CSA, IEC, UL60950-1
Efficiency: 76 %
Unit Weight: 630 g
Output Power: 300 W
Input Voltage: 90 VAC to 132 VAC, 180 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kV
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 60 A
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
