Measurement Range:
PE contact on steel - 1.27 - 30500mm (0.05 - 1200")
PE Contact on plastics - 2.54 - 127mm (0.100 - 5")
EE contact on steel - 2.54 - 914.4mm (0.100 - 36")
EEV contact on steel - 2.54 - 152.4mm (0.100 - 6")
Resolution: +/- 0.1mm (0.01"); +/- 0.01mm (0.001") selectable
Operating Temperature: -10 to 60ºC (14 to 140ºF)
Power Supply: 3 x AA batteries and via USB
Battery Life: Alkaline: greyscale 35 hrs
Nicad: greyscale 10 hrs
NI-MH: greyscale 35 hrs
Gauge Weight: 383g (13.5oz) - including batteries
Gauge Dimensions: 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List: Unit; custom 1” Delay Line Transducer (Rubber Delay Line) & Cable; Couplant; Manual; Certificate of Calibration; AA Batteries and Plastic Carrying Case. PC Software (download) & transfer cable included.
