Resistance: 0.005Ω
Bandwidth (-3dB): 400MHz
Rise time: ≤875ps
Maximum continuous power: 2W
Temperature coefficient of resistance/℃: ±40ppm
Weight: 16g
Maximum pulse energy that can be sustained: 5J
Coaxial shunt diameter: 10mm
Coaxial shunt length: 48mm
Wire type input pin size: Diameter 1.5mm/length 15mm
Bolt type input bolt size: Bolt diameter M3/length 15mm
PCB copper foil with bolt type contact: 10mm diameter conductive ring
Signal output connector: BNC
Maximum torque of fixed nut: 0.5 N* m
