Max.Capacity (kgf ): 10
Rated output ( mV/V): 2.0±0.2
Zero balance ( mV/V): 0.0±0.1
Combined error (%): 0.03 (D3/C3)
Repeatability (% ): 0.02 (D3) / 0.01 (C3)
Creep (30 min.) ( % ): 0.03 (D3)/ 0.017 (C3)
Temperature effect on
+ Zero value (%/℃ ): 0.03(D3) / 0.014 (C3)
+ Output value (%/℃): 0.03(D3) / 0.011 (C3)
Excitation
+ Recommend (V ): 10
+ Maximum ( V): 15
Resistance ():
+ Input (Ω ): 400±20
+ Output ( Ω): 350±3.5
Insulation ( ㏁): ＞2000 @50V DC
Compensated temp.range (℃): -10~+40
Operating temp, ( ℃ ): -20~+80
