Acoustic Parameters
Mic Array: 64 channels
Frequency: 2k ~ 65k Hz
SPL: 28 ~ 132 dB
Dynamic Range: Up to 12 dB
Distance: 0.3 ~ 120 m
Camera
FOV: 66° (H) × 52° (V)
Resolution: 5 MP
Focal Length: 2.26 mm
Autofocus: Yes
LED Light: Yes
Display
Resolution: 800 × 480
Size: 4.3 inches
Screen: Capacitive touchscreen
Brightness: Max 400 nits, adjustable
Storage
Capacity: 32 GB (internal)
Formats: .jpg (image), .mp4 (video), .wav (audio), .cdat (data)
Video Length: Max 5 minutes
Data Export: USB-C and Wi-Fi
Basic Parameters
Size: 150 × 83 × 27.5 mm / 5.91 × 3.27 × 1.08 inches
Weight: 270 g / 0.595 lbs
Wi-Fi: 802.11 a/b/g/n/ac
Bluetooth: BT 5.2
Battery: 3.85 V, 3900 mAh
Power Supply: 9 V DC / 1 A (USB-C charging)
Battery Life: Up to 4 hours
IP Rating: IP54
Operating Temperature: -10 ~ +50 °C
Storage Temperature: -20 ~ +55 °C
Operating Humidity: 10 ~ 95% (non-condensing)
Software report : yes
Features: Sound visualization & localization, gas leak detection and quantification, partial discharge detection, photo & video recording, automatic/manual frequency filtering, PC software post-processing
Hardware Ports
USB-C: 1 × USB 3.0 (charging, HDMI, data export, headphone output)
Language
Chinese, English, Korean, French, Japanese, Russian, German, Italian, etc.
