Width: 50.8 mm
Height: 21.7 mm
Length: 76.2 mm
Industry: Medical
Approvals: ES60601-1, EN60601-1, EN62368-1, UL62368-1
Dimensions: 76.2 mm x 50.8 mm x 21.7 mm
Efficiency: 89 %
Unit Weight: 80 g
Output Power: 31.2 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 50 Hz to 60 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 650 mA
Output Voltage-Channel 1: 48 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
