Width: 89 mm (3.504 in)
Height: 41 mm (1.614 in)
Length: 152 mm (5.984 in)
Industry: Medical
Approvals: ANSI/AAMI ES60601-1, cUL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1
Compliance: ANSI/AAMI ES60601-1, C-UL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1
Efficiency: 91 %
Unit Weight: 840 g
Output Power: 624 W
Input Voltage: 85 VAC to 264 VAC, 88 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 45 Hz to 66 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 13 A
Output Voltage-Channel 1: 48 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
