Width: 55.88 mm (2.2 in)
Height: 38.1 mm (1.5 in)
Length: 147.32 mm (5.8 in)
Industry: Industrial
Efficiency: 70 %
Unit Weight: 254.016 g
Output Power: 15 W
Input Voltage: 85 VAC to 264 VAC, 110 VDC to 370 VDC
Cooling Method: Convection
Mounting Style: Chassis
Input Frequency: 47 Hz to 440 Hz
Load Regulation: Regulated
Mechanical Style: Open / Enclosed Frame
Isolation Voltage: 3 kVAC
Number of Outputs: 3 Output
Power - Convection: 15 W
Input Voltage - Max: 264 VAC, 370 VDC
Input Voltage - Min: 85 VAC, 110 VDC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 2 A
Output Current-Channel 2: 300 mA
Output Current-Channel 3: 200 mA
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 15 VDC
Output Voltage-Channel 3: - 15 VDC
Operating Temperature Range: - 10 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 10 C
