Test Type: IZOD / CHARPY
Capacity: IZOD 1-11J / CHARPY 1-11J (Option hummer)
Energy Loss: < 2.5%
Recommend Test Range: 20% ~ 80% of hammer capacity
Minimal Display Value: 0.05°C
Impact angle: 150°
PC- Port: TCP/IP
Power Demand: Single phase 100 ~ 240 V
Dimension: 96 x 42 x 75 cm
Weight: 210 kg
Note: choose option suitable nessesary
Option
- SD101-04: Software
- QC-639 CE Protection Cover
- ISO Serial Optional Accessories:
+ IP-0004-00I: Izod vise ISO 180
+ IP-0102-00I: Izod
hammer 1J (Shared by ISO / ASTM)
+ IP-0272-00I:
Izod hammer (Dual range 2.75J and 5.5J) (Shared
by ISO / ASTM)
Izod hammer (Dual range 11J and 22J) (Shared by
ISO / ASTM)
Izod hammer
(Dual range 25J and 50J)(Shared by ISO / ASTM)
+ IP-0005-00I: Charpy vise ISO 179 / For Speed 2.9m/s
Block for Charpy test Speed 2.9m/s
+ IP-0005-20I: Charpy vise ISO 179 / For Speed 3.8m/s
Charpy
hammer 1J / Speed 2.9m/s
Charpy
hammer 2J / Speed 2.9m/s
Charpy hammer
4J / Speed 2.9m/s
+ IP-0503-F0I: Charpy hammer 5J / Speed 2.9m/s
Charpy
hammer 7.5J / Speed 3.8m/s
Charpy
hammer 15J / Speed 3.8m/s
Charpy
hammer 25J / Speed 3.8m/s
Charpy hammer
50J / Speed 3.8m/s
- ASTM Serial Optional Accessories
+ IP-0004-00A: Izod vise ASTMD256
Izod
hammer 1J (Shared by ISO / ASTM)
+ IP-0272-F0A:
Izod hammer (Dual range 2.75J and 5.5J) (Shared
by ISO / ASTM)
Izod hammer (Dual range 11J and 22J) (Shared by
ISO / ASTM)
Izod hammer
(Dual range 25J and 50J) (Shared by ISO / ASTM)
+ IP-0005-00A:
Charpy vise ASTMD 6110
Charpy hammer
1J / Speed 3.46m/s
Charpy hammer
2.7J / Speed 3.8m/s
Charpy hammer
5.4J / Speed 3.8m/s
Charpy hammer
10.8J / Speed 3.8m/s
Charpy hammer 21.6J / Speed 3.8m/s
- QC-640: Impact Specimen V-Notcher
CQC-640 cutter (space for QC-640)
