Comde-Derenda PNS 24DMC-6.1 Automatic Sampling System (1.0 ... 5.5 m³/h, 350 VA)

Volume flow rate: 1.0 ... 5.5 m³/h (Nm³/h)

Accuracy: ≤ 2 % deviation

Sampling duration: 1 min … 1000 h

Power source: 230 V, 50 / 60 Hz

Power requirement: approx. 350 VA

Filters: Filter diameter: 47 mm

Sampling diameter: 41 mm

Dimensions:

Width: 483 mm (19″ rack)

Height (without changer unit): 266 mm (6 height units)

Height (with changer unit): 570 mm (≤ 13 height units)

Required minimum height for installation: 610 mm (≤ 14 height units)

Depth: 361mm

Weight: approx.27.5kg

Interfaces: RS-232: 2

SD drive: 1

GPRS modem (optional): 1

Sound pressure level: acc. to EN 3744:2010 (distance 8 m): < 36 dB(A)

Operating temperature range: -30 … +50 °C

Operating temperature range with cooling (set point value max. 23 °C): -30 … +35 °C

Operating humidity range: 0 … 100 %rH

Datasheet
