GUI interface: Spreadsheet and EasyBuilder
Firmware: In-Sight Explorer 5.1.0 or later
Storage Capacity: 128MB fixed flash memory (unlimited via remote network device)
Ram: 512 MB SDRAM
Sensor: 2/3-inch CCD, global shutter
Lenses: C-mount
Resolution: 2448 x 2048
Acquisition Rate: 16 fps
Discrete Inputs: 1 opto-isolated, acquisition trigger input. Additional inputs available using a compatible I/O module. Unlimited inputs when using an Ethernet I/O system
Discrete outputs: 2 built-in, high-speed outputs. Additional outputs available using a compatible I/O module. Unlimited outputs when using an Ethernet I/O system
Status LEDs: Power, Network Status, Network Traffic, 2 user configurable
Connection: RS-232C
Power Supply: 24VDC ±10%, maximum 600mA
Dimensions (L x W x H): 134.4mm (5.29in) x 124.1mm (4.88in) x 61.4mm (2.42in) with lens
Standard: IP67 with included lens
