Dimensions (L x W x H): 150.5 mm x 101 mm x 45 mm
Weight: 0.94 kg
Scan Rate: Up to 4 kHz (after lowering the sensor window) (Maximum 6 kHz)
Measurement range (height): 106.00 mm
Near field of view (width): 55.00 mm
Middle field of view (width): 72.50 mm
Far field of view (width): 90.00 mm
Operating temperature: 0–45 °C (32–113 °F)
Storage temperature: -20–70 °C (-4–158 °F)
Humidity: < 80% non-condensing
Vibration: 10 to 57, dual amplitude 1.5 mm X,Y,Z, 3 hours per direction
Inputs: Trigger, differential/single ended encoder, laser interlock
Trigger: Input voltage limits: Trig+ - Trig - = -24 VDC to +24 VDC / Input ON: >10 VDC (>6 mA) / Input OFF: <2 VDC (<1.5 mA)
Power supply: 24 VDC +/- 10%, 750 mA minimum
