Algorithms: IDQuick
Resolution: 1280 x 960 Global shutter
Image Sensor: 1/3" CMOS
Acquisition: 45 fps
Maximum Decode Rate: 45 Decodes/Second
Lens Options: 6.2 mm (3-position or liquid lens, 50–250 mm), 16 mm (manual focus or liquid lens, 80 mm–1 m)
Trigger and Tune Buttons: Yes. Quick Setup Intelligent Tuning
Aimer: 2 Green Aimer LEDs
Discrete Inputs: 2 opto-isolated
Discrete Outputs: 4 opto-isolated
Status Outputs: 5 Status LEDs and Beeper
Lighting: Modular/Field Configurable Lighting: Four Independently Controlled, High-power LEDs (Red, White, Blue, IR); Band-Pass Filters & Polarizing Filter Available
Power Supply: Two models with 24V ±10% or PoE (Power over Ethernet)
Power Consumption: <3.0 W (PoE or external power)
Connection: RS-232 and Ethernet Interface
Material: Aluminum
Weight: 142 g
Dimensions (L x W x H):
Straight - 43.1 mm x 22.4 mm x 64 mm
Right-Angle - 43.1 x 35.8 mm x 49.3 mm
Operating Temperature: 0°C–40°C
Storage Temperature: -10°C–60°C
Humidity: <95% non-condensing
Sealing Rating: IP65
