Fundamental Frequency Range: 10 Hz to 600 kHz
Distortion Measurement Range; 0.1% to 100%
Voltage Input Range: 0.3 to 200V
Resolution: 0.001%
Distortion Accuracy
Range: 10Hz - 600kHz / 30 Hz – 300 kHz
100% to 0.3%: ±3% of Full scale / -
0.1%: ±6% of Full scale / ±3% of Full scale
Full scale distortion ranges are: 0.1%, 0.3%, 1%, 3%, 10%, 30%, and 100%
Voltage Accuracy
Range: ±2% / ±5%
0.3V – 30V: 10 Hz – 1 MHz / 1 MHz – 3 MHz
30V – 200V: 10 Hz – 300kHz / 300 kHz – 500 kHz
Instrument Induced Distortion
5Hz to 200kHz : -70 dB
200kHz to 600kHz: -64 dB
Second Harmonic Accuracy for a fundamental of:
10 Hz to 20 Hz : ±1 dB
20 Hz to 20 kHz : ±0.6 dB
20 kHz to 100 kHz: ±1 dB
100 kHz to 300 kHz : +1 dB, -2 dB
300 kHz to 600 kHz : +1 dB, -3 dB
Max input: 200Vrms
Input impedance: >110 kΩ || <70pF
Coupling: AC
Frequency Accuracy: 0.1%
Residual Noise: 25 uV
350 Hz High Pass Filter: 350 Hz ±35 Hz Third order Butterworth; 60 dB/decade
80 kHz Low Pass Filter: 80 kHz ±8 kHz Third order Butterworth; 60 dB/decade
General
Display: 4.3” High Resolution Color TFT
Digital Interface: IEEE-488.2, USB
Size :Approximately 17" W x 3.5" H x 13” D
Temperature range: Operating: 0° to 40°C Within specification: 23°C ± 5°
Humidity: Within specification: 20% to 50% RHnoncondensing
Storage Environment: Temperature Range: 0° to 50°C; Humidity Range: 15% to 80% RH noncondensing
Weight: Approximately 13 pounds
Power supply: 100V, 120V, 220V, 240Vrms, 47Hz to 63Hz, 30VA max.
