Width: 58 mm
Height: 30.5 mm
Length: 132 mm
Region: Universal
Industry: Medical
Approvals: EN60601-1, UL60601-1
Compliance: EN60601-1, UL60601-1
Efficiency: 86 %
Unit Weight: 345 g
Output Power: 60 W
Input Voltage: 90 VAC to 264 VAC
Connector Type: Barrel Connector
Cooling Method: Convection
Mounting Style: Desktop
Load Regulation: Regulated
Mechanical Style: External
Center Pin Length: 12 mm
Isolation Voltage: 5.66 kVDC
Number of Outputs: 1 Output
DC Output Connector: 2.5 mm Barrel Plug (2.5x5.5)
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Connector A Polarity: Center Positive
DC Output Cord Length: 1.2 m
Output Current-Channel 1: 3.33 A
Output Voltage-Channel 1: 18 VDC
AC Plug included/required: Required
Operating Temperature Range: 0 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: 0 C
