External:
- Exterior Dimension (W×D×H, mm): 1197×617×1969
- Interior Dimension (W×D×H, mm)
+ Left : 450×522×1742
+ Right : (Upper) 491×542×86/ (Lower) 491×542×862
- Depth of the Opened Door (mm): Right : 1178
- Weight (kg): 515
Left Cabinet:
- Quanity (EA): 3
- Maximum Load (kg): 75 / per piece
- Spill Tray:
+ Quanity (EA): 1
+ Load Capacity (l): 12.5
Right Cabinet:
- Upper Cabinet:
+ P.P. Tray Quanity (EA): 2
+ Load Capacity (ℓ): 18 / per piece
+ Maximum Load (kg): 25 / per piece
- Lower Cabinet:
+ P.P. Tray Quanity (EA): 2
+ Load Capacity (ℓ): 18 / per piece
+ Maximum Load (kg): 25 / per piece
Duct Exhaust Connection
The exhaust vent located at the top of the product effectively discharges odors and harmful gases and automatically closes the exhaust vent in the event of a fire to block the outflow of harmful gases to the outside.
Automaticlly Closed Door
A low melting point lead sigeon unit automatically closes the door to prevent secondary damage if a fire occurs and the temperature rises above a certain temperature.
Expandable Interior Material
The expandable interior finish between the door and the frame swells in response to heat in the event of a fire, sealing the gap between the door and the frame and blocking the entry of heat into the cabinet. It keeps the temperature inside constant.
Fire resistant filler double replenishment structure
A double supplement with a fireproof filler between the outer wall and the inner wall blocks the inflow of heat and keeps the temperature of the interior space constant
