Measure range: 0~10/100/1000ppm/1%/25% O2
Sensor: Fuel cell oxygen sensor
Accuracy:
0.01~9.99ppm O2:±5% FS
10.0~99.9ppm O2:±3% FS 0.5% in full range
100~1000ppm O2:±2% FS T90<60s(25°C)
Repeatability:
0.01~9.99ppm O2:±2.5% FS 60 minutes, from air (20.94%) to 10 ppm
10.0~99.9ppm O2:±1.5% FS Fuel cell oxygen sensor
100~1000ppm O2:±1% FS one year (recommended)
Stability:
0.01~9.99ppm O2:±2.5% FS/7d 24VDC,0.2A
10.0~99.9ppm O2:±1.5% FS/7d 200~240VAC,50/60Hz
100~1000ppm O2:±1% FS/7d RS485(standard)/RS232(optional)
Response time: T90<60s(25°C)
Power supply: 220VAC±10%,50/60Hz
Communication: RS485(standard)/RS232(optional)
Signal output: 2 sets,Relay contact point capacity:24V DC,0.2A
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/ 1-5V (You can set the mode freely).
Environment temperature: 0~45°C Environment Humidity:<80%RH
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Analyzer weight: Net weight 5.0 kg
Analyzer size: L×W×H=305mm×270mm×144mm
