Measure range: 0~10/100/1000ppm/1%/25% O2
Accuracy:
0.01~9.99ppm O2:±5% FS
10.0~99.9ppm O2:±3% FS
100~1000ppm O2:±2% FS
Repeatability:
0.01~9.99ppm O2:±2.5% FS
10.0~99.9ppm O2:±1.5% FS
100~1000ppm O2:±1% FS
Stability:
0.01~9.99ppm O2:±2.5% FS/7d
10.0~99.9ppm O2:±1.5% FS/7d
100~1000ppm O2:±1% FS/7d
Sensitivity: 0.5% in full range
Response time: T90<60s(25°C)
Recovery time: 60 minutes, from air (20.94%) to 10 ppm
Sensor: Fuel cell oxygen sensor
Calibration cycle: one year (recommended)
Relay contact point capacity: 24VDC,0.2A
Power supply: 200~240VAC,50/60Hz
Communication: RS485(standard)/RS232(optional)
Environment Temperature: 0~45°C Environment Humidity:<80%RH
Sample temperature: 0~45°C
Sample flow rate: 1~1.5L/min (1.2L/min Recommended)
Sample gas pressure: atmospheric conditions±10% (Gas outlet should be atmospheric conditions)
Analog output: 1 set,4-20mA/0-20mA/0-1V/0-5V/0-10V/1-5V (You can set the mode freely).
Analyzer Size: L×W×H=260.5mm×160mm×194mm
Instrument weight: self-weight 4.7 kg
