Frequency Range:
DC: 2 Hz ~ 45GHz
AC: 10MHz to 45GHz
10MHz Precise Frequency Reference
• Frequency accuracy: ± (last calibration date × aging rate + temperature stability + calibration accuracy)
• Aging rate: ± 5×10^-10/year
• Temperature stability: ± 5×10^-8
• Calibration accuracy: ± 4×10^-8
Span
• Range: 0Hz (zero span), 10Hz – the highest frequency of the model
• Accuracy: ± (0.1%× span＋span/ (sweep points number-1))
Sweep Time Range
• Span≥10Hz: 1ms – 16000s
• Span=0Hz: 1us – 16000s
RBW: 0.1Hz-20MHz (1, 2 ,3 ,5, steps)
VBW: 1Hz-20MHz (1, 2 ,3 ,5, steps)
Signal Analysis Bandwidth
• 10 MHz (Standard)
• 40 MHz (Optional)
• 200 MHz (Optional)
• 600 MHz (Optional)
• 1.2 GHz (Optional)
SSB Phase Noise (Carrier 1GHz, 20℃ -30℃)
• -95 dBc/Hz @ 100Hz offset
• -112 dBc/Hz @ 1kHz offset
• -122 dBc/Hz @ 10kHz offset
• -122 dBc/Hz @ 10kHz offset
• -135 dBc/Hz @ 1MHz offset
Trigger Source: Free, Line, Video, External level (front panel), External level (back panel), Burst RF, Timer
Trigger Detector: Normal, positive peak, negative peak, sample, video average, power average, voltage average
1dB Gain Compression
• 10MHz – 100MHz: 0dBm
• 100MHz – 1GHz: 0dBm
• 1GHz – 8GHz: +5dBm
• 8GHz – 50GHz: +5dBm
Residual Response: 200kHz – 8GHz: -90dBm
Power Supply: AC 100 – 240V: 50 – 60Hz
Dimension: Excluding the handle, brackets: （426±4）mm ×（177±4）mm ×（450±4）mm
Weight: About 25kg (different configuration cause different weight)
See more detail information in the Datasheet
