Frequency Range:
DC: 3Hz ~ 50GHz
AC: 10MHz～50GHz
10MHz Precise Frequency Reference
• Frequency accuracy: ± (last calibration date × aging rate + temperature stability + calibration accuracy)
• Aging rate: ± 1×10^-7/year
• Temperature stability: ± 1.5×10^-8 (20°C ~ 30°C) ± 5×10^-8 (0°C – 55°C) (±1.5×10^-8)
• Calibration accuracy: ± 4×10^-8
Span
• Range: 0Hz (zero span), 10Hz – the highest frequency of the model
• Accuracy: ± (0.1%× span＋span/ (sweep points number-1))
Sweep Time Range
• Span≥10Hz: 1ms – 6000s
• Span=0Hz: 1us – 6000s
RBW: 1Hz-3MHz (step by 1, 2 ,3 ,5) / 4 MHz / 5 MHz / 6 MHz / 8 MHz / 10MHz / 20MHz
VBW: 1Hz-3MHz (step by 1, 2 ,3 ,5) / 4 MHz / 5 MHz / 6 MHz / 8 MHz / 10MHz / 20MHz
Signal Analysis Bandwidth
• 10 Hz – 10 MHz (Standard)
• 40 MHz (Optional)
• 200 MHz (Optional)
• 550 MHz (Optional)
• 1 GHz (Optional)
SSB Phase Noise (Carrier 1GHz, 20℃ -30℃)
Feature
• -96 dBc/Hz @ 100Hz offset
• -115 dBc/Hz @ 1kHz offset
• -125 dBc/Hz @ 10kHz offset
• -125 dBc/Hz @ 100kHz offset
Typical
• -105 dBc/Hz @ 100Hz offset
• -118 dBc/Hz @ 1kHz offset
• -129 dBc/Hz @ 10kHz offset
• -129 dBc/Hz @ 100kHz offset
Trigger Source: Free, Line, Video, External level (front panel), External level (back panel), Burst RF, Timer
Trigger Detector: Normal, positive peak, negative peak, sample,video average, power average, voltage average
1dB Gain Compression
• 20MHz – 40MHz: -3dBm
• 40MHz – 200MHz: +1dBm
• 200MHz – 4GHz: +3dBm
• 4GHz – 9GHz: -1dBm
• 9GHz – 50GHz: +1dBm
• 50GHz – 67GHz: -1dBm
Residual Response
• 200kHz – 9GHz: -100dBm
• All frequency: -100dBm (rated value)
Input Connector: 2.4mm (male), impedance: 50Ω
Power Supply: AC 100 – 240V: 50 – 60Hz
Dimension
• Excluding the handle, brackets: 426 (W) × 177 (H) × 460 (D) mm
• Including the handle, brackets: 510 (W) × 190 (H) × 534 (D) mm
Weight: About 25kg (different configuration cause different weight)
See more detail information in the Datasheet
