Imaging and optical data
IR resolution: 160x120 pixels, focal plane array (FPA), uncooled microbolometer
Field of View(FOV): 29.8°x 22.6°
Minimum focus distance: 0.2m (0.66ft.)
Spatial resolution (IFOV): 3.33 mrad
Thermal sensitivity/NETD: < 0.08°C @ +30°C (+86°F) / 80mK
Image frequency: 50Hz
Focus: Manual
Zoom: 1-20x continuous, digital zoom
Rotate: 0-360°, continuous change by 1°
Image presentation
Display: 3.5" TFT , capacitive touch screen
Image modes: IR image, visual image, picture in picture
Picture in Picture: IR area on visual image or visual image area on IR
Color palettes: GRAY/GRAY IRON/IRON/RAINBOW/FEATHER
Measurement
Object temperature range: Low range: –20°C to +150°C (–4°F to +302°F), High range: 0°C to +400°C (+32°F to +752°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Screening temperature range: 32°C~42°C
Temperature measurement accuracy: ±0.5°C
Test area: 1 meter distance: 44cmx33cm, 2 meters distance: 88cmx66cm
Full-fi eld high-temperature tracking: Red diamond frame mark
High temperature alarm setting: Default 37.3°C
Measurement analysis
Spotmeter: 3
Emissivity adjustable: 0.01~1.0 Adjustable
Emissivity table: Emissivity table of predefined materials
Line: 2 lines(horizontal and vertical)
Area: 3 boxes with max. /min. /average
Automatic hot /cold detection: Auto hot or cold spotmeter marks
Isotherm: Detect high/low temperature/interval
Measurement corrections: Emissivity, ambient temperature, distance, relative humidity, offset temperature
Set-up
Laser / Floodlight: <class2 / white LED floodlight
Set-up commands: Local adaptation of units, language, date and time formats, information of camera
Language selection English, Chinese, French, German, Spanish
Storage of videos/images
Storage media: 4Gbytes Micro SD card
Video storage format: Standard MPEG-4, 640x480@30fps, on memory card > 60 minutes
Image storage format: Standard JPEG, including measurement data, on memory card > 1000 pictures
Storage mode: IR/visual images; simultaneous storage of IR and visual images
Digital camera
Built-in visible light digital camera: 640x480 Pixels
Data communication interfaces
USB interfaces: USB-mini, data transform between camera and PC
Video out: Composite (PAL and NTSC)
Power system
Battery: Lithium polymer battery, 4 hours operating time
Input voltage: DC 9V to 12V
Charging system: In camera (AC adapter)
Power management: Automatic shutdown and sleep mode (user selectable)
Environmental data
Encapsulation: IP65
Drop test: 2m
Size(HxWxD): 243mm x 103mm x 160mm
Weight: 920g
Accessories:
Hard transport case, 22mm lens, Sun Visor, Tripod base, AC charger/Power supply, Battery, Camera lens cap, software CD-ROM, Handstrap, micro SD card, USB cable & RCA cable, Gift box.
