Imaging and optical data
IR resolution: Focal plane array (FPA), uncooled microbolometer, 160x120
Field of View (FOV): 21°x15.6°
Spatial resolution (IFOV): 2.26mrad
Thermal sensivity/NETD: < 0.05°C @ +30°C (+86°F) / 50 mK
Image frequency: 25Hz
Focus: Manual
Image presentation
Display: 3.5" 640x480 touch screen
Image modes: IR image, visual image, picture in picture, AUF
Color palettes: IRON, Rainbow, Grey, Grey Inverted, Brown, Blue-red, hot-cold, Feather
Measurement
Object temperature range: 0°C~+450°C (+32°F to +842°F)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Set-up
Set-up commands: Local adaptation of units, language, date and time formats, information of camera
Language selection: English, Chinese, French, German, Spanish, Japanese, Korean, Portuguese, Italian
Storage of videos/images
Storage media: 4Gbytes eMMC or 8GB SD card
Video storage format: Standard MPEG-4, 640x480@30fps, on memory card > 60 minutes
Digital camera
Built-in visible light digital camera: 2M Pixels
Data communication interfaces
USB interfaces USB-micro, data transform between camera and PC, Remote control, live video
Wi-Fi connectivity: Wi-Fi connectivity allows to send images and data to mobile devices remote control, live video
Power system
Battery: Lithium polymer battery, 4 hours operating time
Input voltage: DC 5V
Charging system: In camera (AC adapter)
Size(HxWxD): 228mm x 100mm x 98mm
Weight: 520g
Accessories:
Hard transport case, 7.5mm lens, Tripod base, AC charger/Power supply, Battery, software CD-ROM, Handstrap, micro SD card, USB cable, Gift box.
