Imaging and optical data
IR Resolution: 384x288
Focal Plane Array: Uncooled microbolometer/8~14um
Field of View: 41x31
Focal length: 9mm
Spatial resolution: 1.89mrad
NETD (@25°C,F#1.0): <0.5°C 50mK
Image Frequency/ Focus: 50Hz/ Manual
Measurement
Object temperature range: 32°C to 42°C (-89.6°F to +107.6°F), –20 to 150°C (–4 to 302°F),0 to 650°C (32 to 1202°F)
Face tracking: Intelligent face tracking, detect 10 faces at the same time
Built-in visible digital camera: 2M Pixels
Accuracy: ±0.5°C (32~42°C, Screening mode) ±2°C, Normal temperature measurement range
Image adjustment
Color palettes: Grey/Grey Inverted/IRON/Rainbow
Imageing Algorithm: Intelligent image enhancement
Interfaces
Video output/ Digital output: RJ45 Enthenet/ Standard PAL /USB UVC
Communication interface: HTTP/RTSP
Power/ Power consumption: 5 VDC/ <1.8W @25°C
Size（HxWxD): 85x75x60mm
Weight: 193g
