Imaging and optical data
IR Resolution: 160x120
Focal Plane Array: Uncooled microbolometer/8~14um
Field of View: 29.8x22.6
Focal length: 7.5mm
Spatial resolution: 3.33mrad
NETD (@25°C,F#1.0): <0.8°C 80mK
Image Frequency/Focus: 50Hz/Manual
Measurement
Object temperature range:
32°C~42°C(–89.6°F~+107.6°F)
–20~150°C (–4~302°F)
0~650°C (32~1202°F)
Face tracking: Intelligent face tracking,detect 10 faces at the same time
Built-in visible digital camera: 2M Pixels
Accuracy: ±0.5°C (32~42°C, Screening mode) ±2°C, Normal temperature measurement range
Image adjustment
Color palettes: Grey/Grey Inverted/IRON/Rainbow
Imageing Algorithm: Intelligent image enhancement
Interfaces
Video output/Digital output: RJ45 Enthenet/ Standard PAL /USB UVC
Communication interface: HTTP/RTSP
Power/ Power consumption: 5 VDC/ <1.8W @25°C
Size (HxWxD):85mm x 75mm x 60mm
Weight:193g
