Printing Technology: Thermal Transfer
Resolution: 300 dpi
Maximum Print Width: up to 105.7 mm
Print Speed: up to 300 mm/s
Printable Media: Paper, cardboard, PET, PE, PP, PI, PVC, PU, acrylate, Tyvec
Label Width: 5 – 116 mm
Media Thickness: 0.03 – 0.5 mm
Media Weight: up to 180 g/m²
Roll Diameter: up to 205 mm
Core Diameter: 38.1 – 76 mm
Winding: Outside or inside
Ribbon Winding: Outside or inside
Ribbon Roll Diameter: up to 72 mm
Ribbon Core Diameter: 25.4 mm
Ribbon Length: up to 360 m
Ribbon Width: 25 – 114 mm
Dimensions (W × H × D): 240 × 317 × 435 mm
Weight: 6 kg
Gap Sensor: Labels or punched marks and material end, marks on transparent media
Reflective Sensor (from below): Labels and material end, marks on opaque media
Memory: 256 MB RAM, 50 MB IFFS
Battery: Battery for current date/time, real-time clock
Interfaces: RS232C, USB 2.0 for PC, Ethernet 10/100 Mbit/s, USB host
Control Panel: 4.3-inch color LCD touchscreen, 480 × 272 px resolution
Power Supply: 100 – 240 VAC, 50/60 Hz, PFC
Power Consumption: Standby < 10 W / Typical 80 W / Maximum 200 W
Operating Temperature / Humidity: +5 – 40 °C / 30 – 85 %, non-condensing
Storage Temperature / Humidity: 0 – 60 °C / 20 – 85 %, non-condensing
