Power: 150kW
Voltage: 1500V
Current: 400A
Dimension (W*D*H mm): 1000*900*2200
Weight (kg): 1500
AC Input
AC input Voltage: 3P+N+PE, 380VLL±10%(std)
Frequency: 47-63Hz
Efficiency: ≥90%
Power Factor: 0.95
THDi: ≤3%
Output
Output Modes: CV, CC, CP and CR
Load Regulation: 0.1%FS
Line Regulation: 0.1%FS
Voltage Ripple: 0.2%FS
Stability: 0.2%FS
Current Rise Time (0%~90%): <5ms
Current Rise Time (-90%~90%): <10ms
Voltage Regulation Time (0-100% Load change): <5ms
Power Accuracy: 0.3%FS
Voltage Accuracy: 0.1%FS
Current Accuracy: 0.3%FS
Power Resolution: 0.1kW
Voltage Resolution: 0.1V
Current Resolution: 0.1A
Measurements
Measurement accuracy Power: 0.3%FS
Measurement accuracy Voltage: 0.1%FS
Measurement accuracy Current: 0.3%FS
Others
Standard Interface: LAN/RS485
Protection: OVP, OCP, OPP, OTP
CE Conformity: EN 62040-1, EN 62040-2
Protection Level: IP21
Cooling: Forced Air Cooling
Temperature Operating: 0~40°C, Storage: -20~85°C
Operating Humidity: 20-90%RH (None Condensing)
