Width: 3.2 mm
Height: 1.17 mm
Length: 5.4 mm
Approvals: UL, cUL, TUV
Tolerance: +/- 5 C
Resistance: 7 mOhms
Unit Weight: 0.050 mg
Contact Rating: 9 VDC / 25 A, 6000 cycles
Voltage Rating: 28 VDC
Maximum Voltage: 28 VDC / 25 A, 100 cycles
Rated Temperature: + 72 C
Reset Temperature: > 40 C
Maximum Temperature: + 72 C
Maximum Leakage Current: 200 mA
Minimum Holding Voltage: 3 V
Maximum Breaking Current: 5 VDC / 60 A, 100 cycles
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 30 C
