- Input rating:
Input Voltage: 0~80 V
Input Current:
Low: 0~6 A
High: 0~60 A
Input Power: 400 W
Channels: 1
Minimum Operating Voltage:
Low: 0.15 V at 6 A
High: 1.5 V at 60 A
- CV mode:
Range:
Low: 0 to 18 V
High: 0~80 V
Resolution:
Low: 1 mV
High: 10 mV
- CC mode:
Range:
Low: 0~6 A
High: 0~60 A
Resolution:
Low: 0.1 mA 1 mA 0.1 mA
High: 1 mA 10 mA 1 mA
- CR mode:
Range:
Low: 0.05 Ω to 10 Ω
High: 10 Ω to 7.5 kΩ
Resolution: 16-bit
- CW mode:
Range: 400 W
Resolution: 10 mW
- Transient mode (CC mode):
T1&T2: 20 µs to 3600 s / Res: 5 μs to 10 ms
Accuracy: 5 μs + 100 ppm
- Readback voltage range:
Low: 0 to 18 V
High: 0~80 V
Resolution:
Low: 0.1 mV
High: 1 mV
- Readback current range:
Low: 0~6 A
High: 0~60 A
Resolution:
Low: 0.1 mA
High: 1 mA
- Readback power range: 400W
Resolution: 10 mW
General (typical):
Short Circuit:
Current (CC):
Low: 6 A
High: 60 A
Voltage (CV): 0 V
Resistance (CR): 25 mΩ
Input Terminal Impedance: 300 kΩ
Dimensions: 3.2” x 6.7” x 22.6” (82 x 170.5 x 573 mm)
Weight: 11 lbs (5 kg)
