Max. Range （optional）: 50N，500N，5KN，10KN，20KN，50KN
Precision Grade: Grade 1
Measuring Range of Test Force: 1％～100％ FS（full range）
Display Error of Test Force: Within ±1% （indicating value） / Within ±0.5% （indicating value）
Resolution of Test Force: ±1/500000 of max. force （There is no grade in the whole process， and keep the constant resolution throughout the whole process.）
Load Sensor: Standard configured one tension and pressure sensor （maximum load）; Up to 5 sensors can be added.
Valid Test Width: 450mm（can be widened as required）
Valid Tensile Space （excludes clamp）: 1000mm（can be lengthen as required）
Test Speed: 0.001～400 mm/min
Display Error of Displacement: Within ±0.5%（Indicating Value） / Within ±0.2%（Indicating Value）
Control System of Deformation（Optional）:
A.Large deformation measure system：the minimum gauge distance is 10mm, the deformation range is 800mm.
B.Small deformation measure system：gauge distance：25mm，50mm， 100mm; deformation range：5mm，10mm，25mm
Control Accuracy of Deformation Speed: Within ±0.5% of indicating value （large deformation or small deformation can be selected by customers）
Safety Device: Electronic limit protection
Lifting Device of Working Platform: Fast/slow speed automatic control， can move by yourself
Return Function: Manual or automatic. After the test is completed，it returns to the initial position at the highest speed.
Overload Protection: If the maximum load exceeds 10%，the machine will be automatically stopped.
Clamp: A set of clamp （special clamps can also be designed according to the customers’ sample specifications.
Overall Size: 880mx 530x 1800mm （L x W x D）
Power System: Servo machine + transmission + high accuracy ball screw
Power Supply: 220V， 50HZ
Power: 1.0 KW
Weight: 380 KG
