Power Rating: 75 W
Connector: SMA
VSWR and Frequency Range:
1.10:1 from DC to 1 GHz
1.25:1 from 1 to 3 GHz
Coolant Method: Dry, Convection Cooled
Impedance: 50 Ohms
Temperature: -40 to 40 °C (-40 to 104 °F)
PIM: -110 dBc Min.
Humidity: 95% non-condensing
Standard Attenuation Values: 3 dB
Dimensions: Dia. 7.3” x 2.3”/ 186 x 59 mm
Weight: 1.6 lbs./726 g
Finish: Black Anodized Aluminum
