Resolution (H x V Pixels): 1936 x 1216 (full resolution) / 1920 x 1200 (default resolution)
Resolution: 2.3 MP
Sensor Type: Sony IMX392LLR-C / Progressive scan CMOS / Global shutter
Sensor Format: 1/2.3 inch
Effective Sensor Diagonal: 7.9 mm
Pixel Size (H x V): 3.45 x 3.45 µm
Frame Rate (at Default Settings): 67 fps (default settings) / 164 fps (default setings, disabled Device Link Throughput Limit)
Mono / Color: Mono
Image Data Interface: USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Synchronization: Via hardware trigger / Via software trigger / Via free run
Exposure Time Control: Programmable via the camera API
Camera Power Requirements: ≈1.9 W (typical) @ 5 VDC
I/O Lines: 4 general purpose I/O (GPIO) lines
Lens Mount: CS-mount
Size (L x W x H): 20 x 29 x 29 mm
Weight: <15 g
Conformity: CE (includes RoHS), EAC, UL Listed, GenICam 2.x (including PFNC 1.x and SFNC 2.x), USB3 Vision, REACH, KC
Software: Basler pylon Camera Software Suite (version 6.0 or higher) Available for Windows, Linux x86, Linux ARM, macOS, and Android
