Focal Length f: 12.7 mm ± 5 %
Aperture Range: F1.4–F16
Image Circle: 16 mm (1”)
Focus Range: 0.1 m to infinity
Optimum Working Distance: 1.0 m
Relative Illumination at Full Aperture: 41 %
Resolution (25 % MTF, Center, Full Aperture): Designed for 64 LP/mm
Optical Distortion: Typical -5.93 %
Angle of View, 1 Format: Horizontal: 56.45° Vertical: 42.51°
Angle of View, 1/1.2 Format: Horizontal: 49.6° Vertical: 31.73°
Wavelength Range: Visible (400–700 nm)
Pupil Magnification, ßP: 50.6
Chief Ray Angle, CRA: 6.7°
Front Focal Length, sF: 12.49 mm
Back Focal Length, sF: 12.55 mm
Principal Point Separation, HH: 29.49 mm
Entrance Pupil Position, sEP: 14.67 mm
Overall Optical Length, d: 67.38 mm
Flange Back: 17.526 mm
Mount: C-mount
Weight: Approx. 175 g
Focus/Iris Operation: Manual Operating angle: 258.3°
